Functional description:
The ten channel prismatic battery sorting machine is an automatic sorting device suitable for square shell batteries. This device is compatible with multiple cell sorting options. The device achieves internal pressure and resistance testing of square shell cells through an internal resistance tester. The parameters of each cell are tested according to the upper computer software settings, and different levels of batteries are moved to different channels according to the judgment results, thus achieving automatic sorting of battery products (the device has a scanning data storage function). The equipment is composed of a feeding mechanism, a code scanning mechanism, a testing mechanism, an automatic sorting mechanism, etc. According to user requirements, the upper computer software is designed and developed. According to the group information, the battery cells are automatically sorted and collected into their corresponding feeders. The operation is simple, the sorting is accurate, and the efficiency is high.

Overview of work steps:

The ten channel prismatic sorting machine consists of a feeding mechanism, a scanning mechanism, a testing mechanism, an automatic sorting and receiving mechanism, etc. Firstly, manually place the entire battery at the feeding assembly line. The feeding assembly line will send the batteries one by one to the scanning area for scanning and binding, and then go to the testing area for data testing. The scanning data will be bound with the QR code. After the testing is completed, the sorting machine will use a robotic arm to put cells of different voltages into the sorting assembly line and flow them into the corresponding gear receiving bin. This cycle of work will continue.
