Handheld laser welding

hanheld laser fiber laser welding machine

Welding Machine Handheld Metal Fiber Laser
ZEKE Handheld Fiber Laser Welding Machine is a new type high-power, high-end continuous welding tool which adopts a high-quality fiber laser source to produce a fiber optic beam. After transmission processing, the light is focused on the work piece to achieve continuous welding. It avoids the two thresholds of thermal strain and post-treatment, and is environmentally friendly and pollution-free, greatly improving the joint strength and quality of welding. Replacing the previously fixed light path with a hand-held type not only facilitates the welding of molds, advertising characters, kitchen utensils, doors and windows, etc., but also makes laser welding possible in outdoor operations, which indicates that the traditional welding of electric welding, argon arc welding, etc. will be replaced by laser welding.


Size infomation

Model

DG1000W

DG-1500W

DG-2000W

DG-3000W

Laser Power

1000W

1500W

2000W

3000W

Laser wavelength

1080nm

1080nm

1080nm

1080nm

Power adjustment range

10-100%

10-100%

10-100%

10-100%

Spot adjustment range

0.2-5mm

0.2-5mm

0.2-5mm

0.2-5mm

Weld thickness

2mm

3mm

4mm

6mm

Power consumption

5kw

7kw

9kw

11kw

Operating Voltage

220-240VAC-50Hz/60Hz

220-240VAC-50Hz/60Hz

380-415VAC-50Hz/60Hz

380-415VAC-50Hz/60H
